Slanke vliesgevel voor grote glasoppervla

Product photos

Aliplast’s curtain walls are specifically designed to meet the high demands of contemporary international architecture.

MC55 is a façade system with a slim appearance with various exterior solutions as a finish. Aliplast offers the possibility of joints in both straight cut and stepped cut versions depending on customer requirements.

With profile depths of up to 275 mm, various mullion-transom connections and reinforced glass supports, larger spans are made possible with large glass weights.

MC55 is also perfectly compatible for the integration of our extensive range of windows, doors & sliding windows. MC55 is also extendable to roof applications.

Thanks to the different variants of spacers, the MC 55 (Passive) tops the charts in terms of insulation values, which is not unimportant in today’s market.

Features

View width 55 mm
Acoustic insulation up to 46.5(-2;-5.6)
Burglarproof RC2
Resistance to wind 2100 Pa / 3150 Pa
Watertightness Class RE2100
Air transmission Class 4
UF value MC55 Passive 1.1 W/m²K
Uf value MC55 1.2 W/m²K
Glass thickness 1-74 mm
Depth mullion 50-275 mm
Depth transom 91-266 mm

Our strengths

Unlimited design freedom
More efficient and fast assembly
Larger load capacities for heavy glazing
